How it Works

abrasive-separatorOptional abrasive separators are designed to keep blast media free of contaminants, thereby extending media life and minimizing media waste. During operation, media from the blast cabinet is suctioned through a hose into the abrasive separator. As the media spiral in a downward vortex, the heavier, reusable media particles are thrown to the outside, passing through a filter bag or optional deluxe dust collector that traps any debris. Dust and fine particles collect in the center of the vortex where they are pulled out through the suction tube and exhausted into a filter bag or dust collector. The cleaned media is then returned to the cabinet to be used again. Free of contaminants, the media is more efficient and provides more consistent results. Abrasive separators are ideal when blasting painted, rusted or corroded parts.

Abrasive Separator Diagram

Features

  • 11-gauge welded steel construction
  • Easy installation (welding required)
  • Tunable for different media
  • 300, 450 & 600 CFM sizes available
  • Internal filter screen
  • Front-loading media door
  • 110V motor (other voltages available)
  • Zippered dust bag

click on highlighted model number to view picture

Abraive Separator Model Specifications

Model

Specifications

300 CFM

Available on models SM3624C, MM4824C, MM4224S and MM4824S.

Suited for medium to heavy amounts of blasting where media separation is needed.

Suited for use with glass beads or other fine media only.

Optional enclosed dust collector available.

450 CFM

Available on models SM36C, MM48C, MM4224S, MM4230S, MM4824S and MM4830S.

Suited for medium to heavy amounts of blasting where media separation is needed.

Suited for most types of media, including glass beads and aluminum oxide.

Optional enclosed dust collector available.

Available on models MM4040S, MM4836C, MM6024S, MM4848S, MM6048S, MM7248S and MM9648S.

Suited for medium to heavy amounts of blasting where media separation is needed.

Suited for most types of media, including glass beads and aluminum oxide.

Optional enclosed dust collector available.

Retrofit
Packages
Retrofit abrasive separators are available in 300, 450 and 600 CFM. All retrofit packages come complete with all components, hoses, and fittings necessary to adapt to most existing cabinets, such as media pick-up hose, air intake baffles for blast cabinet, 5/8” ID siphon hose, media pick-up hose port and zippered dust bag. Optional enclosed dust collector available.
