K9 System – Heavy-Duty, Table-Top Model, Mini-Barrel Tumbler
K9 System – Heavy-Duty, Table-Top Model, Mini-Barrel Tumbler
The K9 system was originally created as a heavy-duty, industrial grade barrel tumbler for the jewelry industry. The hard-working system can be used for deburring, polishing, and cleaning just like the larger tumblers but on a small, portable scale.
K9 System – Heavy-Duty, Table Top Model, Mini-Barrel Tumbler
The K9 System – Heavy-Duty, Table-Top Model, Mini-Barrel Tumbler is engineered for heavy-duty, industrial use like the larger Tumblers. The small size of the entire unit provides versatility and can be used almost anywhere. The K9 is perfect for small batch sizes and parts such as nuts, bolts, screws, and in the jewelry industry.
Benefits
Compact, Heavy Duty Tumbler
Wet or Dry Processing
Quick Loading and Unloading
Industrial Grade Engineering
Short & Long Cycle Time Applications
Ideal for Small Parts
Perfect for the Jewelry Industry
Applications
Deburring
Polishing
Burnishing
Cleaning and Rust Removal
Scale Removal
Jewelry Polishing
Typical Uses
Small Batch Production Runs
Small Part Deburring and Polishing
Jewelry Polishing
Lab Testing and R&D Environments
Specifications
K9 System Specifications
K9 Series Features & Parts
K9 System Components & Features
Barrel
Horizontal
Closed
Hexagonal Shape
Plastic
9" Diameter x 4" Wide
11/2 Quart Capacity
Solid Door/Lid
Drive
Direct Drive via: Gear Motor
1 Phase/60 Cycle/115V
Controls
On-Off Switch Plus Line Cord and Plug
Bench Space
11" Wide x 18" Deep
15" High (Including Barrel)
Optional
Accessories
Drain Door
K9 Catch Pan - Fits Under Barrel
K9 Separating Screen - Fits in Pan. Screen is Constructed of 1/4" Perforated Metal (Other Screen Sizes Available)
