PPB Series – Industrial Grade, Portable Pressure, Abrasive Blasting System
The PPB Series is an economical, Industrial Portable Sandblaster Blasting System designed for industrial applications of all kinds. These systems can be used with a wide variety of dry abrasive blast media and are engineered for ease of use and portability.
PPB Series – Industrial Grade, Portable Pressure, Abrasive Blasting System
The PPB Series – Industrial Grade, Portable Pressure, Abrasive Blasting System will blast away rust, paint, and other unwanted deposits. Portable sand blasting equipment to pressure blast allows abrasives to penetrate into the deepest pitted areas of a part to remove rust, paint and debris. A wide range of abrasive grit media can be used with these blasters.
The PPB Series of portable sandblasting equipment is ideal for body, paint and welding shops and for use in refinishing vehicles, boats, monuments, brick buildings, and industrial equipment. This is cost-efficient, professional, portable sand blasting equipment at its best!
An Air Filter Moisture Separator is included with some models of the PPB portable sandblast machines and is optional on others. A moisture separator will filter excess water from the incoming air supply.
Our quality sandblasting equipment is designed with safety in mind. A pressure gauge monitors internal vessel pressure. The abrasive material metering valve is easily closed for operator safety. Shut-off is quick and simple. All tips and nozzles are tough and durable.
For the utmost in operator safety, we recommend the use of the special light-duty vented blast hood that is supplied with all pressure blasters. Heavy-duty canvas and air-supplied hoods are optional, available protection. Gloves provide an extra margin of safety.
Benefits
- Economical and Easy to Use
- Multiple Sized Pots for Every Application
- Available Moisture Separator for Optimal Blasting
- Portable Tank Design for Ease of Movement
- Easy to use, Recessed Top for Easy Media Loading
- Adjustable Abrasive Flow Valve
- Single Handle Designed for Multiple Nozzle Sizes
- ASME Certified Pressure Tanks
- Usable With Nearly All Types of Dry Abrasive Blasting Media
Applications
- Paint Stripping
- Surface Preparation
- Peening
- Cleaning
Typical Uses
- Smaller Blasting Jobs
- Periodic use in Industrial Applications
- Pool Tile Blasting
- Auto and Truck Body and Frame Stripping
- Mold Removal
- Fire Damage Cleaning
Specifications
PPB Series Specifications
PPB Series Model Components & Features |
|||||
|---|---|---|---|---|---|
Model |
KF65DM |
KF100DM
|
KF110DM
|
KF150DM
|
KF300DM |
Control System |
Deadman | Deadman | Deadman | Deadman | Deadman |
Air
|
80-125 PSI | 80-125 PSI | 80-125 PSI | 80-125 PSI | 80-125 PSI |
Recommended
|
25-30 CFM | 25-30 CFM | 25-30 CFM | 25-30 CFM | 25-30 CFM |
Height |
29.5" | 34" | 32" | 37" | 40" |
Tank Size |
12" x 17" | 10" x 25" | 12" x 22" | 12" x 27" | 16" x 28" |
Tank
|
0.65 ft3 | 0.9 ft3 | 1.1 ft3 | 1.5 ft3 | 2.5 ft3 |
Capacity |
50-60 lbs. | 90-100 lbs. | 90-110 lbs. | 150-160 lbs. | 225-250 lbs. |
ASME
|
Yes | No | Yes | Yes | Yes |
Tank Closure |
Manual Pull Up |
Manual Pull Up |
Manual Pull Up |
Manual Pull Up |
Manual Pull Up |
Blast Time |
20-30 min. | 30-45 min. | 35-50 min. | 45-60 min. | 1-2 hrs. |
Blast Hose |
1/2" I.D. x 10 ft. |
1/2" I.D. x 8 ft. |
1/2" I.D. x 10 ft. |
1/2" I.D. x 15 ft. With Quick Disconnect Coupling |
1/2" I.D. x 25 ft. With Quick Disconnect Coupling |
Included Ceramic
|
Two 1/8" One 3/32" |
One 1/8" One 3/32" |
Two 1/8" One 3/32" |
Two 1/8" One 5/32" |
Two 1/8" Three 5/32" |
Valves |
|
||||
Plumbing Connection |
None | None | None | None | None |
Pressure Gauge |
Yes | Yes | Yes | Yes | Yes |
Sealing
|
3 | 3 | 3 | 3 | 3 |
Wheels |
6" | 6" | 8" | 8" | 10" |
Housing |
Welded Steel Frame |
Welded Steel Frame |
Welded Steel Frame |
Welded Steel Frame |
Welded Steel Frame |
Blast Hood |
Soft Hood | Soft Hood | Blast Hood With Bump Hat | Blast Hood With Bump Hat | Blast Hood With Bump Hat |
Moisture
|
Optional | Optional | Optional | Included | Included |
Optional Accessories |
|||||
System Handle Options |
|---|
Deadman System (DM) |
|
Air Consumption/Nozzle Size
|
||||||||
|---|---|---|---|---|---|---|---|---|
Nozzle
|
50# |
60# |
70# |
80# |
90# |
100# |
Abrasive
|
Blast Area*
|
| (General Blasting Pressures) |
||||||||
| 3/32" | 8 | 9 | 11 | 12 | 13 | 15 | 70-100 | 0.5 |
| 1/8" | 15 | 17 | 19 | 21 | 24 | 26 | 125-175 | 1-1.5 |
| 5/32" | 26 | 30 | 34 | 38 | 43 | 47 | 175-250 | 2-2.5 |
| 3/16" | 33 | 38 | 43 | 48 | 53 | 58 | 275-400 | 3-3.5 |
| 1/4" | 58 | 67 | 76 | 85 | 94 | 103 | 500-700 | 4-4.5 |
| 5/16" | 91 | 105 | 119 | 133 | 146 | 161 | 800-1100 | 5-5.5 |
| 3/8" | 130 | 151 | 171 | 191 | 211 | 232 | 1200-1600 | 6-6.5 |
| 7/16" | 178 | 206 | 233 | 260 | 286 | 315 | 1700-2200 | 7-7.5 |
| 1/2" | 232 | 268 | 304 | 340 | 376 | 412 | 2300-2800 | 8-8.5 |
Nozzle Specifications |
||||||||
|---|---|---|---|---|---|---|---|---|
Air Consumption/Nozzle Size(Cubic Feet Per Minute [CFM] Required at Pressures [PSI] Shown) |
||||||||
| (General Blasting Pressures) |
||||||||
| 3/32" | 8 | 9 | 11 | 12 | 13 | 15 | 70-100 | 0.5 |
| 1/8" | 15 | 17 | 19 | 21 | 24 | 26 | 125-175 | 1-1.5 |
| 5/32" | 26 | 30 | 34 | 38 | 43 | 47 | 175-250 | 2-2.5 |
| 3/16" | 33 | 38 | 43 | 48 | 53 | 58 | 275-400 | 3-3.5 |
| 1/4" | 58 | 67 | 76 | 85 | 94 | 103 | 500-700 | 4-4.5 |
| 5/16" | 91 | 105 | 119 | 133 | 146 | 161 | 800-1100 | 5-5.5 |
| 3/8" | 130 | 151 | 171 | 191 | 211 | 232 | 1200-1600 | 6-6.5 |
| 7/16" | 178 | 206 | 233 | 260 | 286 | 315 | 1700-2200 | 7-7.5 |
| 1/2" | 232 | 268 | 304 | 340 | 376 | 412 | 2300-2800 | 8-8.5 |
* Note: Blast Area Coverage Per/Minute and Abrasive Consumption are Approximate Guidelines. Abrasive Material Used, Technique, and Surface Blasted May Alter Coverage and Consumption.
Additional Information
| Selected Package Gross Weight | 1000 lbs |
|---|
KF150DM
KF110DM
KF100DM
