What is Shot Peening?: Shot peening is a typical manufacturing method intended to improve the fatigue life and durability of metal components. Small metallic bullets are propelled at high speeds onto the surface of a metal component throughout the procedure. This blog post will go through what shot peening is, how it works, and the many types of media used in the process.
Shot peening is a cold working procedure that involves bombarding the surface of a metal component with metallic shots, often made of steel or other alloys. A shot peening machine propels the shots at high speeds, creating little dimples or indentations on the surface of the metal component. These indentations form a compressive stress layer on the surface, which increases the component’s fatigue life and durability.
Shot peening is a technique that is extensively used in the production of aerospace components, automotive parts, and industrial machinery. It is an efficient method for enhancing the strength and lifespan of metal components while lowering the chance of failure due to fatigue or stress.
What is the mechanism for shot peening?
Shot peening is the process of forcibly striking a surface with a spherical metallic, glass, or ceramic particle known as a shot. This intense impact causes the surface to distort plastically. When a cluster of projectiles strikes the surface, multiple depressions form, enveloping the component in a layer of compressive stress on the metal surface.
Techniques and Materials for Shot Peening
Shot peening is commonly done with either air blast systems or centrifugal blast wheels. Air blast systems use compressed air at high pressure to propel projectiles through a nozzle and onto the workpiece. A centrifugal blast wheel uses a fast-revolving paddle wheel to propel the peening material by leveraging centrifugal force. This is accomplished by intentionally changing the location of the media entry to influence the timing of the media release. Ultrasonic peening, wet peening, and laser peening are three more shot peening techniques that do not require media.
Peening media possibilities include cast steel shot, ceramic or glass beads, and cut wire. Wire shot is often preferred because of its ability to maintain its spherical shape as it deteriorates, as opposed to cast shot, which can fracture into sharp fragments and damage the workpiece. Cut wire can last five times as long as a cast shot and is more cost-effective. However, using equipment to recover shot fragments throughout the procedure can help with the purification and repair of shots and feeders, as well as the replacement of damaged media.
What is the purpose of its usage?
Shot peening offers the primary benefit of prolonging the lifespan of a component by generating a deliberately induced layer of compressive stress. This stress layer enhances the component’s ability to withstand fatigue, including corrosion fatigue, stress corrosion, and cavitation erosion. Additionally, shot peening aids in preventing the formation and spread of cracks.By generating compression forces, which counteract metal fatigue, the formation and spread of cracks in the material are prevented. Internally, stress corrosion cracking is reduced through plastic deformation induced by shot peening and laser peening techniques, which help alleviate tensile stress in the affected sections. Nevertheless, the presence of tensile strains within a material is less concerning since surface cracks are less prone to initiate within the interior of the material.
Evaluating the Impact of Shot Peening
The magnitude of the surface residual compressive stresses induced by shot peening would vary based on factors such as the intensity and extent of the peening media.
John Almen developed a technique for evaluating the impact of shot peening called the ‘Almen Strip’. This method measures the compressive stresses generated by the procedure. The magnitude of the blast stream can be quantified by assessing the distortion of the almen strip. This is accomplished when the strip reaches 10% deformation and is subsequently subjected to the same level of intensity for twice the duration. Once the strip is observed to deform by an additional 10%, the intensity of the blast stream can be quantified.
The extent of the process’s spread can also be measured using an Almen round, which was created by R. Bosshard. This method quantifies the proportion of the surface that has been marked by evaluating fluctuations in the angle of the blast stream. Due to the conical shape of the blast stream, the shot impacts the material surface from different angles. Employing overlapping passes can enhance the extent of covering, whereas a surface under compressive stress can be achieved with less than 50% coverage. It is crucial to optimize the extent of coverage in order to achieve the desired surface impact. Several factors can influence coverage, such as the frequency of strikes (shot flow), the duration of exposure, the characteristics of the shot (size, chemistry), and the features of the workpiece. Visual inspection is commonly employed to evaluate the extent of coverage, although the relationship between coverage and the inspection procedure is not directly proportionate due to its random character. For instance, when we say there is 100% coverage, it means that every spot on the material’s surface has been hit many times. On the other hand, 150% coverage indicates that at least five hits have happened at 52% of the locations. Similarly, 200% coverage means that at least five impacts have occurred at 84% of the places. A smaller shot size results in a higher number of impacts per pound. This reduces the required exposure time. Additionally, a harder shot provides greater coverage compared to a soft shot. This is because the harder shot may penetrate deeper, creating larger impressions.
Inadequate or excessive covering decreases the fatigue life of the workpiece. Excessive peening can cause the workpiece’s surface to undergo excessive cold working, which may result in fatigue cracking. Hence, it is crucial to consider the material qualities in conjunction with the peening intensity and exposure time.
Media Types Used in Shot Peening
The type of media used in it is an important aspect in determining the process’s success. The following are some of the most regularly utilized media types in shot peening.
1. Steel Shot: The most widely used medium in this process is steel shot. It is a tough material capable of withstanding high speeds and pressures. Steel shot is good at forming a compressive stress layer on the surface of a metal component, extending its fatigue life and increasing its durability.
2. Glass Beads: For delicate or sensitive applications, glass beads are typically utilized in this process.. They are gentler on the metal component’s surface and can create a compressive stress layer similar to steel shot.
3. Ceramic beads: Ceramic beads are a common choice for shot peening components that demand a high level of precision. They are effective in producing a homogeneous compressive stress layer on the metal component’s surface.
4. Cut Wire: A type of media typically used in this process for irregular or complex shapes is cut wire. It has the ability to reach locations that other forms of media cannot.
The Uses of Shot Peening
Shot peening has numerous applications in diverse industries. The following are some of the most typical uses.
1. Aerospace: In the aerospace industry, this process is often used to extend the fatigue life and durability of airplane components such as landing gear, turbine blades, and engine components.
2. Automobile: In the automobile industry, this process is used to increase the longevity and performance of engine components such as crankshafts, connecting rods, and valve springs.
3. Industrial Machinery: This process is also used to improve the fatigue life and durability of industrial machinery such as gears, bearings, and springs.
Shot Peening’s Benefits and Drawbacks
Shot peening offers benefits like as enhanced strength and increased resilience to fatigue, even when applied to intricate geometric components. The procedure is widely recognized and very affordable, with rigorous research and quality standards in place to ensure its efficacy. Furthermore, the media and equipment are easily accessible.
In addition to enhancing material properties, shot peening can generate a textured surface that can be beneficial in specific applications.
Benefits of Shot Peening:
1. Improves fatigue life and durability of metal components, lowering the likelihood of failure due to stress or fatigue.
2. Low-cost: This process is a low-cost method of increasing the performance and longevity of metal components.
3. Non-destructive: This process is a non-destructive procedure that does not damage the metal component’s surface.
Disadvantages:
The pebbly surface resulting from the technique can be useful in certain applications, but it may be unpleasant in others. Shot peening has the potential to cause distortion in parts with precise tolerances, although this is less of a concern when using fine particle shot peening.
1. Material limitation: This process is only effective on specific materials, such as metals, and may not be appropriate for other materials.
2. Shape limitation: This process is limited to specific shapes and may not be suited for irregular or complex shapes.
3. Requires specialist equipment: To accomplish this process safely and successfully, specific equipment and qualified professionals are required.
Software programs or computer applications
Shot peening is a widely employed technique in several industries, such as medical, aerospace, and automotive, to enhance the surface characteristics of components. Illustrative elements comprise [1]:
Components for machinery
- Camshafts
- Metal springs
- Connecting rods
- Crankshafts
- Spur gears
- Pistons
- Tool accessories are used for drilling holes in various materials.
- Propeller shafts
- Blades used in compressors
- Turbine blades
- Aircraft undercarriage
- Epidural probes
Furthermore, shot peening can also be employed for the purpose of eliminating sand in foundries, removing cores, removing scales, and achieving the desired surface polish for castings utilized in engine blocks and cylinder heads.
The procedure is extensively employed to alleviate tensile stresses generated during airplane repairs due to work hardening. Shot peening can be used to replace the tensile stresses generated by procedures like grinding with advantageous compressive stresses. Shot peening has the potential to enhance fatigue life by up to 1000%, depending on variables such as shot quality, material, intensity, and coverage.
Shot peening can also serve aesthetic objectives by generating a surface roughness that enhances light scattering more efficiently than sandblasting and similar techniques.
The procedure can also be utilized to administer material onto metal surfaces by employing a supplementary powder or liquid containing the intended surface coating. In this application, the projectile is propelled through the powder or liquid, resulting in the deposition of a coating on the workpiece as a result of the impact from the peening process. This technique has been employed for the purpose of incorporating ceramic coatings and administering solid lubricants onto surfaces. However, the resulting coverage is unpredictable because to the disorderly and unpredictable character of the peening process.
Conclusion
Shot peening is a good way to increase the fatigue life and durability of metal components. Metallic shots are propelled at high speeds into the surface of a metal component, forming a compressive stress layer that increases its performance and lifetime. The medium used in shot peening is an important aspect in determining the process’s effectiveness. Steel shot is the most typically used media, however other materials such as glass beads, ceramic beads, and chopped wire can also be utilized depending on the need. Shot peening can be conducted safely and successfully with the assistance of a competent finishing business, enhancing the performance and longevity of metal components in a variety of sectors.
FAQs
Does shot peening result in material removal?
Shot peening is a process that can eliminate elevated areas on the surface of a material. The surface sections of the material have lower levels of compressive strain compared to the deeper regions. However, most of the external stress raisers can be eliminated through polishing.
Does the process of shot peening result in an increase in hardness?
Shot peening, being a cold working method, can result in a rise in surface hardness.
The distinction between shot blasting and shot peening lies in their respective processes and intended outcomes.
Shot blasting is a method employed in industry to alter the surface of a component. The procedure operates based on the notion of abrasion. A high-pressure stream of abrasive particles is used to drive onto the surface of a component in order to achieve various effects such as smoothing rough surfaces, roughening smooth surfaces, shaping surfaces, or removing surface impurities. Shot blasting is commonly employed to prepare a surface for the following processes, such as the application of paint to welds.
Shot peening, as previously explained, distinguishes itself from shot blasting by its purpose of enhancing surface material qualities through the application of compressive stresses.
How much does shot peening cost?
Shot peening is often seen as an unnecessary expense. It is considered an additional step in the manufacturing process. Nevertheless, considering this cost could result in future monetary benefits. Reducing issues such as fatigue, stress corrosion, and other surface failure processes can enhance the part’s performance. It can decrease maintenance and overhaul expenses. Additionally, surface treatments can decrease customer grievances and boost consumer trust.
Despite the initial expense, shot peening is more affordable if you consider the losses due to ignoring it. There could be breakdown claims, lost production time, or expensive redesigns and replacements in the long run. The cost of shot peening varies based on factors like the methods and media utilized. However, it is clear that the expense of having shot peening is greater than the repercussions of neglecting the procedure.
